Technical Parameters:

• External Dimension: 2220mm*590mm*820mm
• Tunnel Size: 2000mm*700mm
• Digital Signal Processing (DSP) technology
• Over 100 frequency
• The overall sensitivity can be adjusted from 0 to level 300
• 16 independent probes& 1,8,16,24 detecting zones
• Working Voltage: AC100-240V/47.5-60Hz
• Power Consumption: 15W
• Weight: about 65Kg
• Working Environment: -20°C~+55°C
• Packing size: 2900mm*500mm*1000mm, GW: 85kg
